Crossover platform, total max. load 300 kg, 9 steps, platform 1200 x 600 mm.

Estimated delivery: 45 days

Crossover platform, total max. load 300 kg, 9 steps, platform 1200 x 600 mm

• Supplied = assembled
• Platform length = 1200 mm
• Platform width = 600 mm
• Clear height = 2120 mm
• Steps incl. platform = 9 pcs
• Material of treads = aluminium, ribbed
• Step depth = 200 mm
• Step width = 600 mm
• Overall max. load = 300 kg
• Reach = 3680 mm
• Frame material = aluminium extruded profile
• Slope = 60°
• Product type = crossover platforms
• Customs tariff number = 76109090
• Country of origin = DEU
• Gross weight = 87 kg
• Weight = 76 kg
• Sustainability = CO 2 footprint calculated
• For bridging machines, conveyor belts or pits
• Safe, fatigue-free working - even over longer periods
• Comfortable ascent - 60° slope
• Overall max. load 300 kg
• Lower end of stairs with foot brackets for floor mounting
• Includes one handrail (1100mm high, can be mounted on the left or right)
• The MUNK crossover bridge is a robust solution for safely crossing machinery, conveyor belts or pits, and is characterised by a sturdy design and fatigue-free working even during extended use
• Take advantage of the construction with extruded aluminium profile, which ensures a high max. load
• The steps are connected with torsion resistance, providing safe and comfortable ascent at a slope of 60°
• The upper stile ends are closed and bolted to the platform side rails
• The total load is 300 kg, allowing safe access and working on the bridge
• The crossover bridge is aimed at in-plant employees, assembly teams and maintenance personnel who regularly need to use elevated crossings
• Foot brackets at the lower end of the stairs for floor fixing allow the construction to be securely and permanently anchored
• The product is particularly suitable where comfortable ascent, reliable stability and a heavy-duty model are required
• One hand rail 1100 mm in height included, can be mounted on left or right
• Second hand rail as an accessory
• Delivered partially assembled - easy final assembly
• Additional sizes, mobile version, 45° angle of inclination as well as alternative designs available on request.
