Balanced crane fork, automatic, effective height 1150 - 1750 mm, light duty version, max. load 2000 kg.

Estimated delivery: 58 days

Balanced crane fork, automatic, effective height 1150 - 1750 mm, light duty version, max. load 2000 kg

• Supplied = assembled
• Max. load = 2000 kg
• Load centre = 680 mm
• Effective height from = 1150 mm
• Fork length = 1000 mm
• Weight compensation = automatic
• Fork width = 125 mm
• Thickness of fork prong = 50 mm
• Material = steel, painted
• Colour = pure orange RAL 2004
• Effective height up to = 1750 mm
• Fork adjustment range = 450 - 950 mm
• Product type = crane forks
• Customs tariff number = 84314100
• Country of origin = DEU
• Gross weight = 180 kg
• Weight = 180 kg
• Sustainability = CO 2 footprint calculated
• Automatically balanced weights against spring pressure
• Low weight
• Adjustable effective height and fork width
• With automatically balanced weights against spring pressure
• Ball bearing mounted, maintenance free PVC roller guide in the support arm
• Infinite width adjustment by manually moving the forks from 450 - 950 mm
• Effective height can be adjusted from 1150 - 1750 mm using locking pins
• Standard fork length 1 m
• Supplied complete with 4 m safety chain
• Forks made of tubular material
• The automatically balanced weights function optimally at a load capacity of 30% or more
• Available upon request with safety cage or loading box in normal size or in any other special size required.
