Canister/drum siphon hand pump, for light oils, solvents, acids, PE.

Estimated delivery: 30 days

Canister/drum siphon hand pump, for light oils, solvents, acids, PE

• Supplied = assembled
• Design of pump = hand pump with immersion tube
• For media = petrol and oil, diesel, anti-freeze, kerosene, solvents, acids and alkalis, water
• Material of pump = PE
• Drive shaft material = PE
• Immersion depth = 830 mm
• Immersion tube diameter = 26 mm
• Pump rate = 20 l/min
• Tube diameter = 26.5 mm
• Suction hose / discharge hose length to cut to size = 1380 mm
• Immersion tube length = 860 mm
• Nominal hose diameter = 21.42
• Thread = 2 inch
• Max. viscosity at +20 °C = 90 mPas
• Weight = 0.35 kg
• Colour = white, red
• Product type = hand pumps
• Customs tariff number = 84138100
• Country of origin = TWN
• Gross weight = 0.62 kg
• Weight = 0.35 kg
• Sustainability = CO 2 footprint calculated
• Suitable for canisters and for 60 and 200 litre drums
• Easy and safe metering
• For light oils, solvents, acids, kerosine, petrol etc
• The hand pump is designed as a siphon pump and is supplied complete with a 1380 mm long discharge hose
• After the suction pipe and the discharge hose have been filled manually, the pump continues to pump automatically
• Venting valve to regulate emptying
• For light oils, a range of light solvents, light thinners, light acids, paraffin etc
• Not suitable for strong acids, nitric acid, strong alkaline solutions, acetone, easily flammable and viscous substances
• Pump rate: 20 l/min Immersion/suction tube length: 860 mm Discharge hose length: 1380 mm Secured using: 2'' barrel bung adapter Maximum liquid temperature: 60 °C Materials in contact with the media: polyethylene Maximum viscosity: 90 mPas Please note: if media compatibility is unclear, please enquire about the suitability of pumps beforehand.
