Electric pallet truck, max. load 1500 kg, lithium-ion battery, LxW 1538 x 540 mm.

Estimated delivery: 40 days

Electric pallet truck, max. load 1500 kg, lithium-ion battery, LxW 1538 x 540 mm

• Supplied = pre-assembled, final assembly by customer
• Lifting range = 80 - 115 mm
• Fork length = 1150 mm
• Fork width = 160 mm
• Distance across forks = 540 mm
• Length = 1538 mm
• Width = 590 mm
• Overall height = 1125 mm
• Min. lifting speed = 0.015 m/s
• Max. lifting speed = 0.022 m/s
• Min. driving speed = 4.4 km/h
• Max. driving speed = 4.9 km/h
• Climbing performance with load = 0.06 %
• Climbing performance without load = 16 %
• Turning radius = 1340 mm
• Thickness of fork prong = 50 mm
• Battery = 24 V / 20 Ah
• Battery charger = 24 V / 8 A
• Working gangway for pallet length = 540 mm
• Roller material = polyurethane
• Fork roller version = tandem
• Fork roller diameter = 80 mm
• Fork roller width = 70 mm
• Steering wheel width = 70 mm
• Steering wheel diameter = 220 mm
• Travel motor = 0.75 kW
• Customs tariff number = 84271090
• Country of origin = CHN
• Gross weight = 170 kg
• Weight = 127.5 kg
• Best value for money
• Low weight and at the same time high stability
• Manoeuvrable handling for confined storage areas
• Lithium-ion battery for fast charging
• Support wheels for stability during travel and with a raised load
• Ergonomic drawbar for safe control
• The electric pallet truck impresses with its agile handling, a low dead weight and, at the same time, high stability
• As a compact electric pallet truck with a lithium-ion battery, it offers a particularly attractive price-performance ratio and enables fast charging for continuous work processes in warehousing and logistics
• The electric pallet truck impresses with its compact design and high manoeuvrability
• This allows the electric pallet truck to be manoeuvred safely in tight warehouse areas and narrow aisles
• The low dead weight facilitates handling, while the robust and reinforced steel construction ensures high durability in daily use
• The battery can be easily removed and flexibly charged, meaning the electric pallet truck remains ready for use at all times
• The integrated lithium-ion battery allows for quick opportunity charging without a memory effect and significantly reduces downtime
• An external charger ensures flexible application possibilities
• The powerful motor ensures constant driving performance with low noise emission at the same time
• Functions such as creep speed mode support precise work in confined spaces
• The ergonomic tiller with intuitive controls ensures safe steering and controlled movement sequences
• Additional safety features such as the emergency stop switch and reverse protection switch increase operational safety
• Stabiliser wheels provide additional stability, improve driving safety and stabilise the pallet truck with a raised load, especially when cornering and on uneven ground
• The electric pallet truck is suitable for warehouses, logistics centres, production areas and the retail sector
• Especially for frequent pallet transport, the electric pallet truck supports efficient processes and reduces physical strain
• It facilitates recurring transport tasks, ensures smooth processes and offers a reliable solution for internal material flow, even where space is limited.
