Outdoor Locker battery charging cabinet, HxWxD 2150 x 460 x 1050 mm, 4 shelves.

Estimated delivery: 40 days

Outdoor Locker battery charging cabinet, HxWxD 2150 x 460 x 1050 mm, 4 shelves

• Supplied = assembled
• Fittings = 4x2-compartment sockets
• Height = 2150 mm
• Transfer height = 2150 mm
• Width = 460 mm
• Depth = 1050 mm
• Internal height = 369 mm
• Internal width = 400 mm
• Internal depth = 600 mm
• Fire resistance = -
• Power supply = 1x230 V
• Internal fittings = without fire suppression system
• Material = sheet steel
• Number of shelves = 4 pcs
• Body colour = charcoal
• Door colour = yellow
• Lock type = electronic PIN lock
• Door type = hinged door
• For media = lithium-ion batteries/rechargeable batteries
• Product type = battery charging safety cabinets
• Customs tariff number = 94032080
• Country of origin = BEL
• Gross weight = 120.3 kg
• Weight = 108 kg
• For safe charging and storage of batteries outdoors
• Four individual charging compartments for shared use by multiple users
• Electronic PIN code locking system for secure access
• Weather resistant cabinet made of zinc plated steel with UV resistant powder coating
• Double-skinned doors for additional weather protection in outdoor areas
• Integrated canopy to protect users from rain
• Door with integrated earth cables
• Ideal for employees with e-bikes or e-scooters
• Can be optimally positioned next to bicycle parking areas, parking spaces or mobility hubs
• Optional aerosol extinguishing system for additional protection in the event of a battery fire
• The LOXXER Outdoor Locker is designed for the safe storage and charging of lithium-ion batteries outdoors, especially for batteries used in e-bikes, e-scooters and similar mobility devices
• By charging the batteries outside the workplace or building, potential risks associated with lithium-ion batteries are physically separated from indoor areas
• The locker is ideal for installation near bicycle shelters, scooter parking areas or mobility hubs at the workplace, offering employees and users safe and clear access for charging
• With four individual charging compartments, a robust, weatherproof construction and integrated charging sockets, the Outdoor Locker offers a reliable solution for the safe charging of batteries for personal mobility devices in shared outdoor areas
• Construction for outdoor use: The locker is specially designed for permanent outdoor installation
• The construction is made of zinc plated steel with a UV-resistant powder coating, making it resistant to moisture, dust and corrosion
• Weatherproof ventilation openings ensure air circulation while protecting the interior of the locker from rain and environmental influences
• The locker also features double-walled doors, which provide additional protection against the elements and increase outdoor durability
• Integrated charging function: The Outdoor Locker has four individual charging compartments designed for the safe storage and charging of lithium-ion batteries
• Dimensions of the compartment HxWxD: 369 x 400 x 600 mm, each compartment is equipped with: - Two 230 V Schuko sockets (16 A) for charging the batteries, maximum battery capacity per locker: 3,68 kWh at 230 V - Perforated shelves that ensure good air circulation around the batteries - Hooks for accessories, for example to store helmets This equipment allows multiple users to charge and store their batteries safely and independently of each other
• Safety and locking: Each locker is equipped with high-quality electronic PIN-code locking systems, enabling secure access for individual users
• The locker doors also feature integrated earthing cables that provide electrical earthing during operation and offer additional safety when charging batteries
• A separate service compartment in the lower section of the locker allows access for electrical installation and maintenance
• The mains connection to the domestic junction box is to be provided on site
• User comfort and installation: The Outdoor Locker is designed for practical use in shared outdoor areas
• An integrated canopy protects users from rain while they access the lockers
• The locker is also prepared for anchoring to a concrete plinth, ensuring a stable installation and preventing shifting or tipping over
• Thanks to its slim design, the locker can be easily set up near bicycle parking areas, mobility hubs or charging zones at the workplace
• Optionally available at extra cost, see accessories below: For additional protection, the locker can be equipped with an optional aerosol extinguishing system
• When activated during a confirmed alarm, the fire suppression system releases a dry aerosol inside the locker within 1 - 2 seconds
• The aerosol interrupts the chemical combustion process at molecular level and helps to bring lithium-ion battery fires under control in less than 30 seconds
• The aerosol distributes itself across all compartments of the locker, offering an extra level of safety in addition to detection, alarm triggering and fire containment
• Can only be ordered in combination with a locker, factory fitted only
• Pre-assembled, final assembly by customer.
