Short combination trolley LHT-G, steel, max. load 3000 kg, gripping range 100 - 203 mm.

Estimated delivery: 53 days

Short combination trolley LHT-G, steel, max. load 3000 kg, gripping range 100 - 203 mm

• Supplied = assembled
• Max. load = 3000 kg
• Gripping range = 100 - 203 mm
• Weight = 61.7 kg
• Product type = chain hoist chassis
• Colour = blue, silver
• Material = steel
• Customs tariff number = 84311000
• Country of origin = CHN
• Gross weight = 62.7 kg
• Weight = 61.7 kg
• Low overall height for efficient use of space
• Higher hook position through direct mounting of the chain hoist
• Less effort and shorter downtimes during maintenance work
• Smooth running due to ball bearings in wheels and gearbox
• Standard overload protection device for high operational safety
• For I-NP beams and HE beams with different flange shapes
• The short combination trolley LHT-G makes efficient use of even limited ceiling heights thanks to its particularly low overall height
• Mounting the chain hoist directly into the trolley makes an additional suspension hook superfluous
• As a result, the load hook reaches a higher position than with conventional combinations of trolley and chain hoist
• More usable lifting height is available, allowing loads to be raised safely even under low ceilings
• The low overall height can also enable a more cost-effective design of bridge and jib cranes
• Ball-bearing wheels and a ball-bearing gearbox ensure smooth running
• Contoured wheel profiles are suitable for both I-NP beams with inclined flanges and HE beams with parallel flanges
• The high-quality surface coating supports reliable use under demanding conditions
• A standard overload protection device increases operational safety and meets key regulations for use on sea-going vessels
• The combination trolley is equipped with a premium chain hoist with 3 m lifting and a 2.5 m long hand chain
• As type G, it features a geared trolley that allows controlled traversing of the load along the beam
• The hoist-trolley combination is suitable for industrial plants, workshops, marine engineering, and maintenance areas with low ceiling heights
• Particularly during repair and maintenance work, the compact design reduces workload and can shorten downtimes.
